Input Voltage Range | 180V to 270V AC |
Output Voltage | 230 V ± 1% (Variable 5%) OR Customize |
Frequency | 47 Hz to 53 Hz |
Power Capacity | 1 kVA to 25 kVA |
Cooling | Air Cooled |
Voltage Regulation | ±1 % |
Duty Cycle | Continues |
Wave-form distortion | Nil |
Ambient | 0 to 45° C |
Environment | Designed for indoor tropical use |
Mounting | Free on wheel |
Controls | 1. Auto/ Manual switch to select mode 2. Increase /Decrease switch to Control O/P voltage in manual mode 3. Pot for variation output voltage in auto mode |
Protection | 1. Under/Over voltage cut off at output 2. Over load & short circuit protection using MCB & MCCB |
Meter | Voltmeter with input/output voltage selector switch |
Indicating lamps | Power ON, High/Low Voltage indication |
